$149.85
The RØDECaster Video is a revolutionary all-in-one video and audio production console that provides intuitive control over every element of your content
Combining powerful video switching, recording and production capabilities with a fully integrated professional audio mixer, it offers a seamless way to streamline and supercharge your workflow for studio productions, video podcasts and interviews, and stream live events with broadcast quality
Key Features Switch between up to six video sources and seven fully customisable scenes at the press of a button High-performance octa-core CPU video and audio processor Four full HD (1080p) HDMI inputs with auto frame rate conversion and two configurable HDMI outputs for viewing program, preview and multiview Two flexible USB-C ports for connecting compatible webcams and RØDE USB audio devices to use as additional video and audio sources Two studio-grade Neutrik® combo jacks with ultra-low-noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments or any other audio source Dual internal wireless receivers for connecting RØDE Series IV wireless microphones Powerful APHEX® audio processing, including an EQ, compressor, noise gate, high-pass filter, de-esser and the legendary Aural Exciter™, Big Bottom™ and Compellor™ effects 2-inch high-resolution touchscreen and versatile rotary encoder for quick configuration and setting adjustment Ability to create seven complex scenes with multiple layers of video, media and graphics, which can be saved and triggered at the touch of a button Automatic chroma keying for effortlessly replacing backgrounds with media or live video inputs Media playback, graphic overlays, keying, transitions and multi-source scene creation all accessible from the front panel Innovative "Inspect" feature for quick-and-easy preview and configuration of any input or scene Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs Stream directly to all major platforms via Wi-Fi or Ethernet, or to streaming software via USB Record directly to external USB storage device, including isolated (ISO) recording for post-editing flexibility Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via RØDE Central
Combining powerful video switching, recording and production capabilities with a fully integrated professional audio mixer, it offers a seamless way to streamline and supercharge your workflow for studio productions, video podcasts and interviews, and stream live events with broadcast quality
Key Features Switch between up to six video sources and seven fully customisable scenes at the press of a button High-performance octa-core CPU video and audio processor Four full HD (1080p) HDMI inputs with auto frame rate conversion and two configurable HDMI outputs for viewing program, preview and multiview Two flexible USB-C ports for connecting compatible webcams and RØDE USB audio devices to use as additional video and audio sources Two studio-grade Neutrik® combo jacks with ultra-low-noise, high-gain Revolution Preamps™ for capturing pristine audio from XLR microphones, instruments or any other audio source Dual internal wireless receivers for connecting RØDE Series IV wireless microphones Powerful APHEX® audio processing, including an EQ, compressor, noise gate, high-pass filter, de-esser and the legendary Aural Exciter™, Big Bottom™ and Compellor™ effects 2-inch high-resolution touchscreen and versatile rotary encoder for quick configuration and setting adjustment Ability to create seven complex scenes with multiple layers of video, media and graphics, which can be saved and triggered at the touch of a button Automatic chroma keying for effortlessly replacing backgrounds with media or live video inputs Media playback, graphic overlays, keying, transitions and multi-source scene creation all accessible from the front panel Innovative "Inspect" feature for quick-and-easy preview and configuration of any input or scene Intelligent auto-switching for seamless hands-free switching of video sources and scenes based on audio inputs Stream directly to all major platforms via Wi-Fi or Ethernet, or to streaming software via USB Record directly to external USB storage device, including isolated (ISO) recording for post-editing flexibility Remote control, user-assignable graphics and media, custom scene building, audio mixing and effects, and other advanced configuration options via RØDE Central
| Brand: | Rode |
| SKU: | RCV-E |
| Store: | Commertech |
| Dimensions mm: | Length: 132.5 Width: 305.9 Height: 61.4 |
| Analog Audio Inputs: | 2 combo jacks (microphone, line or instrument) with Revolution Preamps™ |
| Wireless Audio Inputs: | 2 Series IV wireless receivers |
| Digital Audio Inputs: | USB 1: 2-in/2-out or multichannel (20-in) output USB 1 Chat (uses USB 1 port): 2-in/2-out with mix-minus USB 2: 2-in/2-out with MFi support USB 4 & 5: compatible with RØDE USB microphones and RØDECaster Pro II and Duo |
| Analog Audio Outputs: | 2 headphone outputs (1/4-inch) 2 balanced line outputs (1/4-inch, L/R) |
| Frequency range: | 20Hz – 20kHz |
| Input gain: | up to 76dB Input |
| Equivalent Input Noise: | -131.5dBV (A-weighted) |
| Streaming Sample Rate / Bit Depth: | 48kHz / 32-bit |
| Audio Recording: | Stereo mix WAV audio file |
| Multitrack Audio Recording: | 9 independent stereo WAV audio files |
| Total Number of Layers: | 9 simultaneous in Preview and Program |
| Downstream Keyers: | 2 (overlays and logo) |
| Transitions: | SMPTE wipes, dip and fade |
| Brand: | Rode |
| SKU: | RCV-E |
| Store: | Commertech |
| Dimensions mm: | Length: 132.5 Width: 305.9 Height: 61.4 |
| Analog Audio Inputs: | 2 combo jacks (microphone, line or instrument) with Revolution Preamps™ |
| Wireless Audio Inputs: | 2 Series IV wireless receivers |
| Digital Audio Inputs: | USB 1: 2-in/2-out or multichannel (20-in) output USB 1 Chat (uses USB 1 port): 2-in/2-out with mix-minus USB 2: 2-in/2-out with MFi support USB 4 & 5: compatible with RØDE USB microphones and RØDECaster Pro II and Duo |
| Analog Audio Outputs: | 2 headphone outputs (1/4-inch) 2 balanced line outputs (1/4-inch, L/R) |
| Frequency range: | 20Hz – 20kHz |
| Input gain: | up to 76dB Input |
| Equivalent Input Noise: | -131.5dBV (A-weighted) |
| Streaming Sample Rate / Bit Depth: | 48kHz / 32-bit |
| Audio Recording: | Stereo mix WAV audio file |
| Multitrack Audio Recording: | 9 independent stereo WAV audio files |
| Total Number of Layers: | 9 simultaneous in Preview and Program |
| Downstream Keyers: | 2 (overlays and logo) |
| Transitions: | SMPTE wipes, dip and fade |
